Rear/main camera focus to infinity not work on LineageOS


Recommended Posts

i got something! I got some system info using this App:
https://f-droid.org/en/packages/com.oF2pks.kalturadeviceinfos/

I did this on freshly flashed Stock ROM, and also on freshly flashed LOS official.

The resulting JSON files were mostly identical, but with a perhaps problemrelated difference:

LOS-official:

"#CAMERA2API=": {
   "0=back<LEVEL3>4048x3040([100, 800])": {
      [...]
      "android.lens.info.focusDistanceCalibration": "1",

Pro1-Stock:

"#CAMERA2API=": {
   "0=back<LEVEL3>4048x3040([100, 800])": {
      [...]
      "android.lens.info.focusDistanceCalibration": "2",

See? Difference? 1 vs 2? Also, the similar section for the front camera has the same value on both systems. (Front cam working for me fine on either ROM.)
Can you guys run this app and export that json on your LOS Pro1, please?

So, I think THIS IS IT! How do we fix this?

(I HOPE the value did not change as I might have used the cam app on the one rom before exporting the json, but I think this is a fixed value... Well this sort of testing woud be a lot easier if I had TWO pro1...)

According to docs "2" stands for "CALIBRATED" and "1" for "APPROXIMATE".

Edited by fxtec-preorder-47xx
Link to post
Share on other sites
  • Replies 53
  • Created
  • Last Reply

Top Posters In This Topic

Top Posters In This Topic

Popular Posts

But Kelloggs on the left are more crisp than their cheap knockoffs on the right, no surprise.

Hoping to balance the negativity in this thread, my F(x)tec Pro1 running LineageOS does not seem to have any camera issues regarding focus (see the attached sample I took today). Running LineageOS 18.

For the record, I don't seem to have this problem on LOS either:

Posted Images

On my LineagOS 16:

"android.lens.info.focusDistanceCalibration": "1"

just like on yours.

However, if I understand the docs correctly, this calibration affects only the object distance that is saved in the EXIF header of the pictures and has no influence on the optical functioning of the camera itself.

As far as I know, auto-focus works by optimising the FFT of the actual picture on the sensor and does not rely on somehow "knowing" the true distance to the object. The distance that is saved in the picture metatdata is then derived from the (optimised) position of the lens with respect to the sensor (which is where said calibration comes in).

Edited by claude0001
Link to post
Share on other sites
10 hours ago, fxtec-preorder-47xx said:

@tdmWhat do you think about the differing values of android.lens.info.focusDistanceCalibration? Do you think you could add this to the LOS code? Or try if it improves focus?

You can try and let me know.

Link to post
Share on other sites
  • 1 month later...

Seems like I have the same problem on LineageOS 17.1. My device has a serial number in the 300 range, so maybe it is really something with early models. Tried it with the preinstalled camera and Open Camera.

  • Like 1
Link to post
Share on other sites

If there's something I can do to help locating the problem, just let me know. But ideally the description of steps should be for stupid people then, as I am not very knowledgeable in this field.

Link to post
Share on other sites

Could it just be a problem with the mounting of the camera that was then somehow fixed softwarewise on Stock? The upper (main) lense seems to be a bit off-centered in the black hole/ compared to the lower lens on my phone.


Link to post
Share on other sites

Further observations in Open Camera:

Very near objects (around 0.50m away): Get sharp when sliding the manual focus to around 30m, stay sharp until ~2000m and go blurred when putting the slider to infinity

Near objects (around 1,50m away): Get almost sharp/ only slightly blurred when sliding the manual focus to around 30m, then there's no change until ~2000m and again the jump to blurred when putting the slider to infinity

Far objects (down the street) : Generally a bit more blurred, apart from that exactly the same behaviour as near objects - Best from 30m on, but no further change until the sudden blur when jumping to infinity.

Edited by Jacob_S
  • Thanks 1
Link to post
Share on other sites

I have also been facing focus woes with the camera. Unfortunately didn't have time to test as @Jacob_S did., I only really use the camera when my wife's phone isn't available (battery died or left phone somewhere) and she wants to take pictures. Other than that only the odd document or work things, with some effort I can focus (involves distancing/approaching the phone to the object instead of relying on the camera focusing).

Thank you @Jacob_S for the effort. Maybe your observations will help solve this issue!

  • Thanks 1
Link to post
Share on other sites
56 minutes ago, agent008 said:

Hi All

@EskeRahn, maybe this should be merged within the general LineageOS thread? Where it might get a better visibility. Thanks

Yeah, has been considering this, but was not quite sure which version of lineage this was all about..... Test 16, released 16, released 17 ... ?

  • Thanks 2
Link to post
Share on other sites
4 minutes ago, EskeRahn said:

Yeah, has been considering this, but was not quite sure which version of lineage this was all about..... Test 16, released 16, released 17 ... ?

For me it's 17.1 Currently running 20201214 (I think). Am updating now to 20210118. Thanks

  • Thanks 1
Link to post
Share on other sites
On 1/18/2021 at 3:48 PM, Jacob_S said:

Also 17.1. 20210118

It seems like the update to 0118 did change something. Now the focus slider in Open Camera does nothing. So near objects are always sharp, far objects always the same blurred.

Edited by Jacob_S
See below, just had the wrong setting active.
Link to post
Share on other sites
6 hours ago, Jacob_S said:

It seems like the update to 0118 did change something. Now the focus slider in Open Camera does nothing. So near objects are always sharp, far objects always the same blurred.

Odd, on mine with 17.1 20210118 the manual focus slider seems to work fine. (I have not tested the far distances though, it being pitch dark outside)

Link to post
Share on other sites
On 1/20/2021 at 2:15 PM, Jacob_S said:

It seems like the update to 0118 did change something. Now the focus slider in Open Camera does nothing. So near objects are always sharp, far objects always the same blurred.

Ooor I was just having the scene mode still on landscape without noticing and nothing changed 😅 So yeah, @EskeRahneverything's still the same.

  • Thanks 1
Link to post
Share on other sites
10 hours ago, Jacob_S said:

I think what is described here is the same as our problem. And according to a post in another thread it was confirmed by F(x)tec to be a hardware defect.

@DieBruine can you tell us here, when you know, if the problem was solved by the repair?



You know, I forgot all about this 😅. I hope to receive that phone within two or three weeks. Thing is, I'm pretty sure they've replaced it with a refurbished one.  On the other hand, I have another Pro1 running LoS 18.1. I will try to take the same picture tomorrow. It will be raining all day today, it's grey dark and wet now. Forecast for tomorrow is partially sunny. So hold on a day.

Link to post
Share on other sites
  • 2 weeks later...

I am now convinced, that it is indeed a hardware problem. Look at those two pictures. I stood straight in front of the wall and fixed the focus to the best I can aquire. Only change between those photos is that I turned my phone by 180°. And on one photo the ceiling is sharp and the picture very blurred, on the other photo the side of the picture is almost sharp and the ceiling is slightly blurry.

Camera left.jpg

Camera right.jpg

Edited by Jacob_S
clarification
Link to post
Share on other sites

If you look at this picture I took on Stock Android, you can also clearly see it, even though the image overall is more sharp. Back then I thought, that it was just the Snapdragon camera software misbehaving.


  • Sad 1
Link to post
Share on other sites

I don't even have the Pro1 yet, but I'm quite sure that the image of that cereals shelf is proof enough that it's not a focus problem, it's that the camera's lens is decentered, internally slanted. There's no way a correctly adjusted lens on such a small sensor (with such a large depth of field) could see the left part of the shelf (halfway) in focus and the right part, which is only marginally further away, already totally out of focus. I'm sorry to say this has to be a defective camera.

Edited by Rob. S.
  • Thanks 2
Link to post
Share on other sites
